Pathcross 1000L

Pathcross 1000L

$10,999.00 Regular Price
$10,499.00Sale Price

 Aodes Pathcross 1000L

The Pathcross all terrain vehicle is designed to take you on rugged, unpredictable journeys, knowing that you are well-equipped to handle any terrain or obstacle in your way.



HIGHER GROUND CLEARANCE, LONGER TRAVEL OF SUSPENSION

Are you looking to conquer more difficult and rough terrains or experience greater thrills?  Pathcross has a 10" ground clearance and a 9.5" travel suspension, which improves vertical travel and allows you to ride more comfortably and smoothly.



ONE BRAKE PEDAL FOR ALL FOUR WHEELS

The stopping force of the hydraulically actuated, four-wheel DISC brakes is transmitted to all four wheels with a single brake pedal push.



MULTI-FUNCTION INSTRUMENT

Vehicle speed, Engine Speed, total miles, Turn signal (left, right). Headlight (High / Low beam), EPS indicator, ECU, Fuel Level, Coolant Temp, Park indicator, oil indicator, Battery indicator and brake failure indicator all integrated.



ADJUSTABLE FRONT DIFFERENTIAL SYSTEM & AUTOMATIC REAR DIFFERENTIAL SYSTEM

Do you have to cope with ruts, dirt, hairpin curves, and secluded areas? PathCross's ability to engage both the front and rear differential systems means you can drive with confidence. This improves performance over uneven ground.

Color
  • FEATURES

    PACKAGE HIGHLIGHTS

    *59" LONGER WHEELBASE

    *BACKREST

    *ADJUSTABLE COILOVER SHOCKS

    *FOUR ALLOY RIMS

    *MULTIFUNCTION DIGITAL DISPLAY

    *TOWING HITCH W./ TRAILER BALL

    *ELECTRIC POWER STEERING SYSTEM

    *FRONT 3500LBS WINCH FRONT & REAR DOUBLE A-ARMS

  • SPECIFICATIONS

    • Engine type: V1000V-twin;Four-stroke:Liquid-cooled

    • Displacement: 1000cc

    • Max power: 44kw/6500 RPM

    • Max torque: 73N.m/5000 RPM

    • Valve Configuration: SOHC

    • Compression ratio: 10.3:1

    • Fuel Delivery System: Fuel Pump

    • Fuel capacity:24.5L

    • Driveline Type: 2WD-4WD

    • Final Drive: Shaft;Selectable 4x4;Front Differential Lock

    • Transmission: CVT

    • Gear Selection: H;L;N;P;R

    • Forward Lights: LED Headlights-High & Low Light

    • Rear Lights: LED Brake Lights & Left/Right Signal lights

    • Starting system: Electric start

    • Ignition system: EFI-DELPHI

    • Suspension Front/Rear: Independent double wishbone

    • Brakes Front/Rear: 4 Wheel Disc Brake;Dual Hydraulic Disc Twin Piston/Hydraulic Disk

    • Front Tread: 960mm(37.8in)

    • Rear Tread: 920mm(36.2in)

    • Front & Rear tire size: 26×9-14 / 26×11-14

    • Top speed: 90km/h(55.9MPH)

    • Dry weight: 420kgs(924lbs)

    • Fuel consumption: 6.8L/100Km

    • Wheelbase: 1490mm(58.7in)

    • Vehicle dimension (L×W×H): 2270x1210x1430mm (89.4x47.6x56.3in)

    • Ground clearance: 300mm(11.8in)
